LN2807 6S 1300KV 5S 1500KV 4S 1700KV Brushless MotorForRC FPV Racing RC Drone Racing

Electric Spec.
Max. P (W)	Voltage (V)		Max. I. (A)	KV	No-load Current (A)		Resistance (mΩ)	Poles	Motor Dim. (mm)	Stator Dim. (mm)	Mounting (mm)	N.W. (g)		Prop. (inch)
1400(6S)	2S~6S		55(6S)	1350	1.8		82	14	φ33*19.6	φ28*7	M3-19*19	52		6"~7"
Thrust Testing Data
Propeller		KV Value		Throttle		Voltage (V)		Current (A)	Thrust Force (g)	Speed (RPM)	Input Power (W)		Efficiency (g/W)
GF7037*3		1350		10%		24.67		0.3	41	3149	6.49		6.28
				20%		24.67		1.1	166	6076	26.40		6.30
				30%		24.65		2.74	375	8822	67.57		5.55
				40%		24.64		5.23	628	11254	128.97		4.87
				50%		24.61		8.18	866	13189	201.29		4.30
				60%		24.57		12.66	1178	15327	311.03		3.79
				70%		24.52		19.13	1570	17586	468.99		3.35
				80%		24.47		26.52	1955	19595	648.99		3.01
				90%		24.40		35.37	2367	21357	862.91		2.74
				100%		24.31		45.81	2722	22783	1113.52		2.44
HQ7X37*3		1350		10%		24.67		0.3	36	3171	6.24		5.80
				20%		24.67		1.0	153	6120	25.19		6.07
				30%		24.67		2.63	352	8909	64.78		5.43
				40%		24.65		5.11	607	11291	126.01		4.82
				50%		24.63		8.05	846	13339	198.27		4.27
				60%		24.59		12.61	1159	15420	309.96		3.74
				70%		24.53		19.10	1529	17642	468.40		3.26
				80%		24.48		26.90	1915	19605	658.61		2.91
				90%		24.41		35.80	2274	21297	873.78		2.60
				100%		24.32		46.19	2537	22602	1123.37		2.26

LN2807 6S 1300KV 5S 1500KV 4S 1700KV Brushless MotorForRC FPV Racing RC Drone Racing

The LN2207 series of brushless motors comes in three different KV ratings: 1700KV, 1900KV, and 2400KV. The KV rating represents the motor's speed constant, indicating the increase in RPM per volt of i...

Parametry produktu

×

Wysokowydajny bezszczotkowy silnik do drona LN5313 6S | 320kV / 350kV / 380kV | Ciąg do 2 kg dla UAV

Wyślij zapytanie

Specyfikacja elektryczna
Maks. P (W)	Napięcie (W)	Maks. ja. (A)	KV	Prąd bez obciążenia (A)		Opór (mΩ)		Polacy	Wymiary silnika (mm)	Wymiary stojana (mm)		Montaż (mm)	NW (g)		rekwizyt (cale)
1810	25,2 ~ 33,6	65	380	0.8		25		14	φ49*32,5	φ42*14		M4-30*30	246		13"~15"
Dane z testu ciągu
Śmigło		wartość kV	Przepustnica		Napięcie (W)		Aktualny (A)		Siła ciągu (g)		Prędkość (obr/min)	Moc wejściowa (W)		Wydajność (g/W)
GF1308-3		380	10%		32		0.36		38.95		1117	11.52		3.38
			20%		31.99		1.11		217.75		2378	35.51		6.13
			30%		31.98		2.432		521.91		3578	77.78		6.71
			40%		31.97		4.498		917.14		4687	143.80		6.38
			50%		31.95		8.101		1468.01		5893	258.83		5.67
			60%		31.92		13.087		2113.34		6998	417.74		5.06
			70%		31.87		19.97		2891.65		8108	636.44		4.54
			80%		31.82		30.557		3884.21		9313	972.32		3.99
			90%		31.74		42.237		4809.52		10294	1340.60		3.59
			100%		31.63		56.802		5848.57		11283	1796.65		3.26
HQ15X7-3		380	10%		24.00		0.3		51		881	8.04		6.30
			20%		23.99		1.1		232		1808	25.33		9.18
			30%		23.98		2.35		520		2676	56.31		9.23
			40%		23.96		4.38		894		3489	104.94		8.52
			50%		23.94		8.24		1433		4394	197.24		7.26
			60%		23.90		13.54		2056		5234	323.51		6.36
			70%		23.86		20.59		2782		6043	491.18		5.66
			80%		23.79		30.04		3627		6824	714.58		5.08
			90%		23.71		41.50		4504		7560	983.97		4.58
			100%		23.65		55.29		5422		8266	1307.54		4.15

Wysokowydajny bezszczotkowy silnik do drona LN5313 6S | 320kV / 350kV / 380kV | Ciąg do 2 kg dla UAV

Bezszczotkowy silnik drona LN5313 został zaprojektowany z myślą o profesjonalnych wielowirnikowych UAV, które wymagają dużego udźwigu i stabilnych parametrów lotu. Dzięki maksymalnej sile ciągu 2 k...

Parametry produktu

×

Dual voltage 230VAC/12VDC into one drive for remote area solar panel power supply system W70 Series with metal shell

Wyślij zapytanie

Product Features:
Dual voltage support for flexible power sources
Designed with a durable metal shell for enhanced protection
Ideal for solar-powered systems
Reliable performance in remote areas

Dual voltage 230VAC/12VDC into one drive for remote area solar panel power supply system W70 Series with metal shell

Product Definition :This motor supports dual voltage inputs (230VAC and 12VDC), allowing it to be used in remote areas with solar panel systems. It is equipped with a robust metal shell for durability...
